TP-Link TL-SX3016F JetStream 16 Port 10GE SFP+ L2+ Managed Switch
Thumbnail 1 Thumbnail 2 Thumbnail 3

TP-Link TL-SX3016F JetStream 16 Port 10GE SFP+ L2+ Managed Switch

☆ ☆ ☆ ☆ ☆
(0 Reviews) | Out of Stock | Brand: TP-Link
৳40100 ৳48922 Save 18%

Key Features

  • Product Type: Network Switch
  • Number Of Total Port: 16 Port
  • Switching Capacity: 320 Gbps
  • Packet Forwarding Rate: 238.08 Mpps
  • Cloud Access: Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
  • Warranty: 2 Years Warranty
Basic Information
Product Type Network Switch
Mounting Type Rack Mountable
Ports & Slots
Number Of Total Port 16 Port
Interface(s) 16× 10GE SFP+ Slots
1× RJ45 Console Port
1× Micro-USB Console Port
Networking & Connectivity
Switching Capacity 320 Gbps
MAC Address Table 32 K
Technical Info
Packet Forwarding Rate 238.08 Mpps
Packet Buffer Memory 24 Mbit
Jumbo Frame 9 KB
Features
L2 and L2+ Features Link Aggregation static link aggregation 802.3ad LACP Up to 8 aggregation groups, containing 8 ports per group Spanning Tree Protocol
802.1d STP
802.1w RSTP
802.1s MSTP
STP Security: TC Protect, BPDU Filter, Root Protect
Loopback Detection
Port based
VLAN based
Flow Control
802.3x Flow Control
HOL Blocking Prevention
Mirroring
Port Mirroring
CPU Mirroring
One-to-One
Many-to-One
Tx/Rx/Both
L3 Features 16 IPv4/IPv6 Interfaces
Static Routing
48 static routes
Static ARP
128 Static Entries
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP Interface Relay
DHCP VLAN Relay
DHCP L2 Relay
Management Features
Centralized Management Omada Cloud-Based Controller
Omada Hardware Controller (OC300)
Omada Hardware Controller (OC200)
Omada Software Controller
Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Management Features Web-based GUI
Command Line Interface (CLI) through the console port, telnet
SNMP v1/v2c/v3
Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log
Physical Specification
Package Contents TL-SX3016F Switch
2× Power Cords
Quick Installation Guide
Rackmount Kit
Rubber Feet
Dimension 440 × 220 × 44 mm
Requirement
System Requierment Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Warranty Information
Warranty 2 Years Warranty
Power Type
Power Supply 100-240 V AC~50/60 Hz

TP-Link TL-SX3016F JetStream 16 Port 10GE SFP+ L2+ Managed Switch

Engineered for high-performance enterprise networks, the TP-Link TL-SX3016F JetStream is a 16-Port 10-Gigabit SFP+ L2+ Managed Switch designed to deliver ultra-fast, reliable, and secure connectivity. With 16 full 10G fiber ports, this switch is built for modern business environments requiring massive bandwidth, ultra-low latency, and advanced management features—perfect for data centers, server farms, and high-demand network cores.The TL-SX3016F features non-blocking switching architecture and a massive 320 Gbps switching capacity, ensuring lightning-fast data forwarding and stable performance even under heavy traffic. Its all-SFP+ interface design allows for maximum deployment flexibility using long-range fiber links, giving you full control over your infrastructure’s speed and scale.Advanced Layer 2+ and Layer 3 Lite features include Static Routing, VLANs, ACLs, DHCP Snooping, IGMP Snooping, QoS, and Link Aggregation, enabling precise traffic segmentation, security enforcement, and optimized performance. These capabilities empower administrators to fine-tune network operations across large, complex environments.Fully integrated into TP-Link’s Omada SDN (Software Defined Networking) ecosystem, the switch supports centralized cloud management, zero-touch provisioning, and intelligent monitoring. Whether through the Omada Controller or mobile app, network oversight is streamlined and scalable across multiple sites.Built in a durable rack-mount metal chassis with dual redundant power supplies and passive cooling design, the TL-SX3016F ensures reliability and continuous uptime.Key Features:16 full 10G SFP+ fiber ports for lightning-fast throughputAdvanced Layer 2+/Layer 3 Lite management320 Gbps switching capacityOmada SDN integration for centralized controlRedundant power design and durable buildThe TL-SX3016F is your gateway to next-generation fiber networking—blending speed, intelligence, and scalability
