TP-Link VIGI C340S 4MM 4MP ColorPro Night Vision Outdoor Bullet IP Camera

TP-Link VIGI C340S 4MM 4MP ColorPro Night Vision Outdoor Bullet IP Camera

Model: VIGI C340S 4MM

Reviews: No reviews yet

Price: 8,800.00৳

Regular Price: 9,999.00৳

Save: 1,199.00৳

Key Features:

  • Brand: TP-Link
  • Usage: Outdoor
  • Type: IP Camera
  • SNR: ≥ 52 dB
  • API: ONVIF
  • Protection: IP67
  • Warranty Details: 1 Year
Buy Now

Specifications

General Information

Brand TP-Link
Model VIGI C340S 4MM
Usage Outdoor
Type IP Camera

Camera

Day/Night Mechanism N/A
IR LEDs N/A
Slow Shutter Yes
Illumination Distance 30 m
Weatherproof Rating IP67
WDR 120dB
Digital Noise Reduction 3D DNR
Max Aperture 4 mm: F1.0
6 mm: F1.0
Shutter Speed 1/3 to 1/10000 s
Camera Lens Fixed focal lens (4 mm / 6 mm)
Image Sensor 1/1.8” Progressive Scan CMOS
Day/Night Switch Day/Night/Auto/Schedule-Switch
Minimum Illumination Color: 0.0005 Lux; 0 Lux with white light
Viewing Angle 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
6mm: Horizontal FOV: 57.1°, vertical FOV: 30.2°, Diagonal FOV: 67.2°
Max. Resolution 2688 x 1520

Lens

Lens Mount M16*P 0.5
Aperture F1.0
Focal Length 4 mm
Lens Type Fixed Focal Lens
DORI Distance 4 mm:
Detect: 70 m (231 ft)
Observe: 29 m (96 ft)
Recognize: 14 m (46 ft)
Identify: 7 m (23 ft)
FOV 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°

Illuminator

White LED Quantity: 4
Range: 30m
IR LED N/A
Illuminator On/Off Control Auto/Scheduled/Always on/Always off


OSD Setting Yes
Image Parameters Switch Yes
Wide Dynamic Range (WDR) 120 dB
SNR ≥ 52 dB
ROI 1 Region
Privacy Mask Up to 4 Masks
Image Enhancement BLC/3D DNR/HLC
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation (90°/270°)

Video

Bit Rate Control CBR, VBR
H.265 Type Main Profile
H.264+ Main Stream Supported
H.265+ Main Stream Supported
H.264 Type Main Profile/High Profile
Video Compression Sub-Stream: H.265/H.264
Main Stream: H.265+/H.265/H.264+/H.264
Video Bit Rate Main Stream: 256 Kbps to 6 Mbps
Sub-Stream: 64 Kbps to 512 Kbps
Main Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Audio

Audio Input Yes
Audio Output Yes
Audio Compression Yes
Environment Noise Filtering Yes
Audio Sampling Rate 8KHz
Audio Communication Two-Way Audio
Audio Bit Rate 64 Kbps(G.711 alaw)

Network

Cloud Yes
ONVIF Yes
API ONVIF
Network Storage NAS (NFS, SMB/ CIFS)
Web Browser Safari® 11 and above
Firefox® 52 and above
Microsoft® Edge 91 and above
Google Chrome® 57 and above
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Client VIGI App, VIGI Security Manager, VIGI NVR, Web
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

ALARM AND EVENT MANAGEMENT

Linkage Method N/A
Output Notification Message Push
Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection

Deep Learning Function

Perimeter Protection Motion, Line-Crossing, Intrusion, Region Entering, Region Exiting, Loitering.
Supports Alarm Triggering by Specified Target Types (Human and Vehicle)
Multi-Target-Type Detection Supports Simultaneous Detection and Capture of Human Body and Vehicle
People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Interface

Alarm N/A
Audio N/A
Reset Button Yes
Built-in Speaker Yes
Button Reset Button
Power DC Power Port
Audio Output Built-in Speaker
Audio Input Built-in Microphone
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port
On-Board Storage Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera

VIDEO/IMAGE

Image Enhancement BLC, HLC, 3D DNR
Video Streaming Sub-Stream
Main Stream
Video Bit Rate Main Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps
Video Compression Sub-Stream: H.265/H.264
Main stream: H.265+/H.265/H.264+//H.264
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Frame Rate & Resolutions Main Stream

Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution: 2688x1520,2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720

Sub-Stream

Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution: 640x480, 352x288, 320x240

SMART FEATURE-SET

Region of Interest 1 Region
Linkage Method Trigger Notification: ONVIF, HTTPS
Basic Event Motion detection, Camera Tampering, Scene Change Detection, Exception(illegal login)
Smart Event Intrusion Detection, Object Abandoned/Removal Detection, Region Entering Detection, Region Exiting Detection, Loitering Detection, Line Crossing Detection, Human Detection, Vehicle Detection

Angle Adjustment (Manual)

Range Pan: -90° to 90°
Tilt: -90° to 90°

Environmental

Operating Temperature -30–60 °C
Storage Temperature -40–60 °C
Operating Humidity 95% or Less (Non-Condensing)
Storing/Storage Humidity 95% or Less (Non-Condensing)

Protection

Protection IP67

Certification

Certifications CE, RCM, BSMI, VCCI, RoHS, NTRA, KC

Power Type

Power Consumption PoE: Class 0
12V DC: Max 10.1W
Power Supply PoE (802.3af/at, class 0)
12V DC ± 5%, 5.5mm Coaxial Power Plug

Physical Specification

Material Back Cover: Plastic
Front Cover: Metal
Materia Other: Plastic
Front Cover: Mental
Package Contents Quick Start Guide
VIGI Network Camera
Mounting Accessories
Waterproof Cable Attachments
Dimensions (H X W X D) 99 × 102 × 236 mm
Product Dimensions (L x W x H) 102× 236× 99 mm

Warranty Information

Warranty Details 1 Year

Description

TP-Link VIGI C340S 4MP 4 mm ColorPro Night Vision Outdoor pellet IP Camera – Professional Surveillance with True-Color Clarity Day and Night

Secure your demesne with perfection utilizing the TP-Link VIGI C340S 4MP 4 mm ColorPro Night Vision Outdoor pellet IP Camera. Engineered for professional-grade guidance, this camera combinesultra-clear 4MP conclusion, ColorPro night unreality, smart discovery features, and robust weatherproofing to deliver unmatched interpretation for home, marketable, and artificial screen operations.

Whether you are covering storefronts, parking areas, gates, or storehouse peripheries, the VIGI C340S offers round the-timepiece, high-description, color-rich monitoring with exceptional features to reduce false admonitions and enhance screen effectiveness.

4MPUltra-High Definition for unusual Clarity

Capture every detail with the VIGI C340S’s 4MP conclusion(2560 × 1440), offering significantly advanced image quality than traditional 1080p cameras. This allows for better facial recognition, license plate interpretation, and precise episode attestation. It's the ideal result for companies and institutions where detail and clarity are overcritical.

4 mm Fixed Lens – Focused Coverage for Key Areas

The 4 mm fixed lens offers a clearheaded field of prospect, full for covering special necks like erecting entries, hallways, or confined out-of-door spaces. It provides a medium-side standpoint that avoids deformation while fastening on targeted areas, icing optimal guidance perfection without gratuitous wide-side distractions.

ColorPro Night Vision – Full-Color videotape Indeed in blackness

Traditional night unreality cameras switch to black and undyed in low-light conditions. The VIGI C340S changes the game with ColorPro Night Vision, offering full-color videotape in low-light and darkness scripts. With its improved image detector and erected-in peripheral warm lighting, the camera ensures rich, vibrant detail around the timepiece — helping you easily identify objects, apparel, and agent colors indeed after black.

Smart Discovery – AI-Powered trouble Recognition

Seasoned with AI-grounded discovery, the VIGI C340S intelligently identifies humans, stir, line-voyage, and intrusion events. This smart guidance point helps minimize false admonitions caused by inapplicable stir similar as creatures or wind-blown objects. You will admit real-time cautions through the TP-Link VIGI app when unusual exertion is detected, allowing nippy action to help events.

Outdoor continuity – erected to Withstand Harsh Conditions

With its IP67-rated waterproof casing, the VIGI C340S is finagled to achieve in grueling out-of-door surroundings. Dust, heavy rain, and extreme temperatures pose no trouble to this inured camera, making it ideal for out-of-door inductions where continuity is a must-have.

Easy PoE Installation – One Cable Does It All

The VIGI C340S supports authority over Ethernet(PoE), which allows both authority and data transmission through a single Ethernet string. This simplifies installation and reduces structure charges, especially in locales where authority access is limited.

Remote Monitoring via VIGI App

Keep your eyes on your property from anywhere in the world with the TP-Link VIGI movable app. View live feeds, access playback, admit stir cautions, and customize settings directly from your smartphone or tablet. Remote guidance has noway been more intuitive and dependable.

Adjustable Storage Options & ONVIF Compatibility

The VIGI C340S supports multitudinous storehouse results involving microSD cards(up to 256 GB), VIGI NVRs, and pall storehouse. With ONVIF compliance, it seamlessly integrates with third-party NVRs and VMS platforms icing ultimate comity and inflexibility for both new and being systems.

Crucial Features

 4MP (2560 × 1440)Ultra-HD Resolution

 4 mm Fixed Lens for Precise Field Coverage

 ColorPro Full-Color Night Vision

 AI Discovery Human, stir, Intrusion, Line-Crossing

 IP67-Rated Weatherproof Outdoor Design

 Erected-in Supplemental Light for Night Clarity

 PoE Brace for Simplified Installation

 Remote Access via TP-Link VIGI App

 Supports microSD(Up to 256 GB) & ONVIF Integration

Conclusion

The TP-Link VIGI C340S 4MM 4MP ColorPro Night Vision Outdoor pellet IP Camera is erected for professionals who demand harmonious, exceptional, and high-quality screen monitoring. Offering full-color night guidance, AI-powered smart discovery, and waterproof interpretation, the VIGI C340S is a smart investment for any serious guidance system.
