TP-Link VIGI C540 4MP Full-Color PTZ IP Camera

TP-Link VIGI C540 4MP Full-Color PTZ IP Camera

Model: VIGI C540

Reviews: No reviews yet

Price: 6,000.00৳

Regular Price: 7,550.00৳

Save: 1,550.00৳

Key Features:

  • Brand: TP-Link
  • Type: Network Camera
  • Day/Night Mechanism: IR Cut Filter
  • Max. Resolution: 2560 X 1440
  • Bit Rate Control: CBR, VBR
  • Lens Type: Fixed Focal Lens
  • Protection: IP66
  • Material: Plastic
  • Warranty Details: 1 Year
Buy Now

Specifications

General Information

Brand TP-Link
Model VIGI C540
Type Network Camera

Camera

Image Sensor 1/3” Progressive Scan CMOS
Shutter Speed 1/3 to 1/10000 s
Slow Shutter Yes
Minimum Illumination 0.005 Lux; 0 Lux with IR/White Light
Day/Night Mechanism IR Cut Filter


Day/Night Switch Unified/ Scheduled/ Auto
Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°)
Image Enhancement BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range (WDR) DWDR
SNR ≥ 52 dB
Image Parameters Switch Yes
Privacy Mask Up to 4 Masks
ROI 1 Region
OSD Setting Yes

Video

Max. Resolution 2560 X 1440
Main Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control CBR, VBR
Video Compression Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
H.264 Type High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile
H.265+ Main Stream Supported
Video Bit Rate Main Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps

Lens

Lens Type Fixed Focal Lens
Focal Length 4 mm
Aperture F1.6
FOV 4mm:
Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
Lens Mount M12
DORI Distance 4 mm:
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft)

PTZ

Pan/tilt Range Pan: 0° to 350°, Tilt: 0° to 120°
Pan/tilt Speed Pan Speed:
Configurable from 8° to 44°/s; Preset Speed: 44°/s

Tilt Speed:
Configurable from 8° to 44°/s, Preset Speed 44°/s
Manual Control Speed Configurable from 8° to 35°/s
Presets 300
Patrol Scan 8 patrols, up to 8 presets for each patrol
Power-off Memory Yes;
Auto restore to previous PT and lens status after power failure
Park Action Yes;
Preset; Patrol Scan
3D Positioning Yes

Angle Adjustment (Manual)

Range Pan: 0° to 348°
Tilt: 0° to 120°

Illuminator

IR LED Quantity: 2
Range: 30m
Wavelength: 850nm
White LED Quantity: 2
Range: 30m
Illuminator On/Off Control Auto/Scheduled/Always on/Always off

Audio

Audio Communication Two-Way Audio
Audio Input Yes
Audio Output Yes
Audio Compression Yes
Audio Sampling Rate 8KHz
Environment Noise Filtering Yes
Audio Bit Rate 64 Kbps (G.711 alaw)

Network

Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
ONVIF Yes
API Open Network Video Interface (Profile S)
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Client VIGI App, VIGI Security Manager, Web UI
Web Browser Google Chrome® 57 and above
Firefox® 52 and above
Safari® 11 and above
Microsoft® Edge 91 and above
Cloud Yes
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

ALARM AND EVENT MANAGEMENT

Linkage Method N/A
Output Notification Message Push
Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Basic Event • Exception ( Illegal Login)
• Video Tampering Detection
• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
Smart Event • Area Intrusion Detection
• Line-Crossing Detection
• People Detection
• Vehicle Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned Detection
• Object Removal Detection
• Abnormal Sound Detection

Interface

Reset Button Yes
Built-in Speaker Yes
Alarm N/A
Audio N/A
Power DC Power Port
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
On-Board Storage Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB
Built-in Microphone Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera

Environmental

Operating Temperature -30–60 °C
Storage Temperature -40–60 °C
Operating Humidity 95% or Less (Non-Condensing)
Storing/Storage Humidity 95% or Less (Non-Condensing)

Protection

Protection IP66

Certification

Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC

Power Type

Power Supply 12V DC ± 5%, Max. 14 W, 5.5mm Coaxial Power Plug
PoE: 802.3at, class 4, Max. 16 W

Physical Specification

Material Plastic
Product Dimensions (L x W x H) 120 × 172 × 198 mm

Warranty Information

Warranty Details 1 Year

Description

TP-Link VIGI C540 4MP Full-Color PTZ IP Camera – Professional-Grade Surveillance for 24/7 Protection

Elevate your security with the TP-Link VIGI C540 4MP Full-Color PTZ IP Camera, a decoration result designed for advanced videotape surveillance in both domestic and marketable surroundings. Offering outstanding image clarity, intelligent discovery, and dynamicpan-tilt-zoom functionality, this PTZ camera ensures that no detail goes unnoticed, day or night. erected for harsh surroundings and grueling lighting conditions, the VIGI C540 is ideal for out-of-door installations in parking lots, business demesne, premises , storages, and public spaces.

Stunning 4MP Resolution forUltra-Clear Surveillance

At the heart of the VIGI C540 is a 4-megapixel detector that delivers high-description videotape at a resolution of 2560 × 1440 pixels. This superior clarity makes it easy to identify faces, license plates, and other important details critical to effective security monitoring. Whether landing wide-angle overviews or zoomed-in close-ups, the VIGI C540 constantly delivers sharp and detailed videotape.

PTZ Capability with 360° Coverage

ThePan-Tilt-Zoom(PTZ) point gives the VIGI C540 a significant advantage over standard fixed cameras. The camera supports 360 ° endless criticizing, 90 ° tilting, and important optic drone, allowing druggies to cover vast areas and concentrate on specific points of interest in real-time. It’s perfect for tracking moving targets, following suspicious conditioning, or fastening on distant objects without losing image quality. Pre-set command routes and voyage patterns further enhance its effectiveness for large-scale monitoring.

True Full-Color Night Vision – Daylight Quality in Darkness

Unlike conventional infrared night vision cameras, the VIGI C540 delivers full-color videotape at night, thanks to its high-perceptivity detector and integrated white LED lights. This advanced Full-Color Night Vision technology enables the camera to give accurate color representation and finer visual details indeed in complete darkness. It's ideal for night security scripts where black-and-white footage is n't sufficient for identification or substantiation purposes.

AI-Powered Smart Detection & Instant Alerts

Equipped with AI-enhanced videotape analytics, the VIGI C540 supports a wide range of smart discovery features, including mortal and vehicle bracket, stir discovery, line-crossing, intrusion discovery, and region entrance/exit cautions. These intelligent features reduce false admonitions by distinguishing between real pitfalls andnon-threatening movements like creatures, murk, or falling leaves. Admit real-time cautions via the VIGI app, dispatch, or FTP for immediate response and peace of mind.

Reliable Outdoor Protection with IP66 Weatherproofing

The camera’s IP66-rated waterproof casing ensures long-term continuity and protection in any out-of-door setting. Whether under scorching sun, heavy rain, or fine conditions, the VIGI C540 maintains optimal performance. Its rugged design makes it suitable for demanding surveillance operations in public structure, critical installations, retail centers, and more.

Multiple Storage Options and Easy Integration

The VIGI C540 offers flexible storehouse results acclimatized to your security requirements. It supports microSD card storehouse up to 256 GB, network videotape reporters(NVRs), and FTP waiters, giving you options for original or network-grounded recording. With ONVIF and RTSP protocol support, the camera integrates seamlessly with third-party software and tackle, making it adaptable to being surveillance systems.

Simplified Installation with PoE and Remote Access

Thanks to Power over Ethernet(PoE) technology, the VIGI C540 allows power and data transmission through a single string, reducing installation complexity and cost. druggies can pierce live videotape, playback recordings, and configure settings ever via the intuitive TP-Link VIGI app or VIGI Security Manager, available for both desktop and mobile platforms.

TP-Link VIGI C540 4MP Full-Color PTZ IP Camera is a smart, dependable, and professional surveillance result. With full-color night vision, intelligent discovery, waterproof design, and flexible deployment options, it provides everything you need for 24/7 security in any terrain. Invest in the VIGI C540 for clearer vision, smarter protection, and complete peace of mind.
