Price: 0.00৳
TP-Link InSight S485 2.8MM VIGI 8MP Full-Color Turret Network Camera
| TP-Link |
| InSight S485 2.8MM |
| Network Camera |
| Yes |
| IR Cut Filter |
| 1/3 to 1/10000 s |
| 1/2.7” Progressive Scan CMOS |
| 0.005 Lux; 0 Lux with IR/White light |
| Unified/ Scheduled/ Auto |
| Yes |
| Yes |
| ≥ 52 dB |
| 1 Region |
| Up to 4 Masks |
| BLC/3D DNR/HLC/SmartIR |
| 120 dB Note: When People & Vehicle Analytics is enabled, only DWDR is supported. |
| • WDR • Mirror • Contrast • Exposure • Saturation • Sharpness • Brightness • White Balance • HLC Adjustable by Client Software • Prevent Overexposure to Infrared Light |
| CBR, VBR |
| High Profile |
| Main Profile* |
| 3840 X 2160 |
| Main Stream Supported |
| Main Stream Supported* |
| Sub-Stream: 64 Kbps to 512 Kbps Main Stream: 256 Kbps to 8 Mbps |
| Sub-Stream: H.265/H.264 Main Stream: H.265+/H.265/H.264+/H.264 |
| • Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution: 3840x2160, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If 120dB is turned on, the frame rate can only support up to 20fps. |
| • Frame Rate 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution: 848x480, 704x576, 640x480, 640x360, 352x288, 320x240 • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If 120dB is turned on, the frame rate can only support up to 20fps. |
| F1.6 |
| 2.8/4 mm |
| M12*P 0.5 |
| • 2.8 mm: Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134° • 4 mm: Horizontal FOV: 91.5°, Vertical FOV: 46.1°, Diagonal FOV: 109.6° |
| • 2.8 mm Detect: 85 m (278 ft) Observe: 35 m (116 ft) Recognize: 17 m (56 ft) Identify: 8 m (28 ft) • 4 mm Detect: 107 m (350 ft) Observe: 44 m (146 ft) Recognize: 21 m (70 ft) Identify: 11 m (35 ft) |
| Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360° |
| Quantity: 4 Range: 30m |
| Quantity: 2 Range: 30m; Wavelength: 850nm |
| Auto/Scheduled/Always on/Always off |
| Yes |
| Yes |
| Yes |
| Yes |
| 8KHz |
| Two-Way Audio |
| 64 Kbps(G.711 alaw) |
| Yes |
| Yes |
| Safari® 11 and above Firefox® 52 and above Microsoft® Edge 91 and above Google Chrome® 57 and above |
| ONVIF Profile S/T/G |
| 3 Main Streams & 3 Sub-Streams |
| VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS |
| Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| N/A |
| Message Push |
| • Message Push • White Light Flashing • Memory Card Video Recording |
| • Intrusion Detection • Line-Crossing Detection • Region Entering Detection • Region Exiting Detection • Object Abandoned Detection • Object Removal Detection • Loitering Detection • People Detection • Vehicle Detection • Abnormal Sound Detection • Scene Change Detectio |
| • Exception ( Illegal Login) • Video Tampering Detection • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts) |
| N/A |
| N/A |
| Yes |
| Yes |
| DC Power Port |
| 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB** |
| Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera |
| -30–60 °C |
| -40–60 °C |
| 95% or Less (Non-Condensing) |
| 95% or Less (Non-Condensing) |
| Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.§ |
| IP67 |
| CE, NTRA, VCCI, KC, BSMI, FCC, IC |
| PoE: 802.3af/at, class 0, Max. 12.5 W 12V DC ± 5%, Max. 11.5 W, 5.5 mm Coaxial Power Plug |
| Metal |
| 0.48 Kg |
| Quick Start Guide VIGI Network Camera Mounting Accessories Waterproof Cable Attachments |
TP-Link InSight S485 2.8MM VIGI 8MP Full-Color Turret
Network Camera – Unmatched Clarity and
Security Around the timepiece
Upgrade your surveillance system with the TP-Link InSight S485 2.8MM VIGI 8MP Full-Color Turret Network Camera , a important and advanced security camera designed to give exacting image clarity, full-color night vision, and intelligent monitoring features. Engineered for both marketable and domestic operations, this slice-edge network camera is a dependable result for 24/7 monitoring with detailed, vibrant footage in any lighting condition.
Crystal-Clear 8MP Ultra HD Resolution
The VIGI InSight S485
boasts an emotional 8MP(3840 × 2160) Ultra HD resolution, delivering
exceptionally sharp and detailed images. With four times the resolution of
standard 1080p cameras, this turret camera ensures that every detail is
captured — faces, license plates, and other critical illustrations appear more easily
than ever. Whether covering wide out-of-door areas or sensitive inner zones,
the VIGI S485 ensures that nothing goes unnoticed.
mm Wide-Angle Fixed Lens
Equipped with a 2.8
mm fixed lens, the camera offers a wide field of view, making it ideal for
covering large spaces similar as parking lots, erecting entrances, services, or
retail bottoms. This wide-angle capability reduces the need for multiple
cameras in open areas, saving installation time and costs.
ColorPro Night Vision for 24/7 Full-Color Monitoring
One of the name
features of the VIGI InSight S485 is its ColorPro night vision technology.
Unlike traditional infrared cameras that display black-and-white footage in low
light, this camera provides pictorial full-color videotape indeed in
near-complete darkness. This is made possible by a high-perceptivity detector
and supplemental warm lighting, which together enhance visibility and object
identification during night operations.
Smart AI Discovery and Alerts
Enhance security
through intelligent AI-powered discovery features, including mortal and vehicle
bracket, stir discovery, intrusion discovery, and line-crossing cautions. These
advanced analytics reduce false admonitions touched off bynon-threatening
movements like creatures or leaves. druggies admit accurate drive announcements
and can act snappily in case of any suspicious exertion.
Remote Access with the VIGI App
Stay connected to
your property from anywhere with the stoner-friendly VIGI app. Live view,
playback, and event announcements are just a valve down on your smartphone or
tablet. The VIGI InSight S485 supports remote access via mobile bias, giving
you real-time mindfulness and control of your surveillance system.
Waterproof and Vandal-Resistant Design
Erected for trustability
in colorful surroundings, this turret camera features an IP67-rated waterproof casing
that protects against rain, dust, and harsh conditions. Its IK10 defacer-resistant
design ensures continuity and continued performance indeed in high-threat or
exposed areas.
Flexible storehouse and PoE Support
The VIGI S485 offers protean
recording options with support for original storehouse via microSD card(up to
256 GB), network videotape reporters(NVR), and pall access. It also supports
Power over Ethernet(PoE), simplifying installation by allowing data and power
to be transmitted through a single Ethernet string. This reduces string clutter
and installation costs.
Easy Integration and ONVIF Compatibility
This camera is ONVIF biddable, icing smooth integration with third-party NVRs and VMS platforms. Whether you are upgrading an being system or erecting a new bone, the VIGI InSight S485 offers flawless comity for professional-grade surveillance setups.
Crucial Features at a regard
✔ 8MP Ultra HD Resolution(3840x2160)
✔ mm Fixed Wide-Angle Lens
✔ Full-Color Night Vision with ColorPro Technology
✔ AI-Powered Human & Vehicle Detection
✔ Remote Access via VIGI App
✔ IP67 Weatherproof and IK10 Vandal-Proof Design
✔ PoE Support and MicroSD Card niche(up to 256 GB)
✔ ONVIF Compliance for System Integration
Conclusion
The TP-Link InSight S485 VIGI 8MP Full-Color Turret Network Camera is the perfect mix of invention, trustability, and intelligent surveillance. Whether you’re securing a business premise, covering a home, or expanding your current security system, this point-packed camera provides the visibility and control you need — day or night, rain or shine.
