Price: 0.00৳
TP-Link |
VIGI NVR4064H |
Network Video Recorder |
64-Channel |
Default: 260Mbps Extended Bandwidth Mode: 320Mbps |
Default: 180Mbps Extended Bandwidth Mode: 320Mbps |
2 Channels • HDMI1 Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz • HDMI2 Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
• HDMI1/HDMI2 Independent output • HDMI1/VGA Independent output Note: HDMI2 and VGA cannot operate simultaneously. If both connections are made, HDMI2 will take precedence and function as the primary output. |
1,4,6,8,9,16,25,32,36,49,64 |
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
G.711A/G.711U/G.726 |
H.265+/H.265/ H.264+/H.264 |
16-Channel † |
• 25fps: 16-ch@2MP、32-ch@720P、64-ch@D1 • 30fps: 4-ch@8MP、6-ch@5MP、8-ch@4MP |
• Manual Recording • Scheduling Recording • Motion Detection Recording |
• Instant Playback • Regular Playback • Tag Playback • Event Playback |
• Regular Backup • Video Clip Backup |
• Play • Pause • Stop • Fast Forward • Fast Backward • Play By Frame • Full Screen • Video Clip • Export Clip • Digital Zoom • Lock Recording • Audio On/Off |
UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
Android, iOS |
Chrome (57+), Firefox (52+), Edge (91+) |
ONVIF Profile S, CGI |
2, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
2 Front USB 2.0 Ports, 1 Rear USB 3.0 Port |
1-ch RCA Input; 1-ch RCA Output |
16/4 |
1, RS232 |
1× AC Jack |
1 |
N/A |
1 |
2 |
1 |
4 SATA Interfaces |
Up To 16 TB Capacity for Each HDD* |
• Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame Note: The alarm function requires the use of a camera. |
• Video Loss • Offline and IP Conflict • Disk Exception • Login Exception • Fan Exception Note: The alarm function requires the use of a camera. |
• Recording • White Light Alarm • Buzzer • Log • Audible Alarm Note: The alarm function requires the use of a camera. |
-40–70 °C |
10%~90% RH Non-Condensing |
NVR: -10–55 °C |
10%~90% RH Non-Condensing |
100-240 VAC, 50 to 60Hz, 1.5A |
• 6.95 W (Without Disk) • 48.38 W (With Disk) |
CE, NTRA, KC, HDMI, FCC, IC, VCCI, BSMI, ONVIF |
4.0 Kg |
5.0 Kg |
17.32 × 12.99 × 1.73 in (440 × 330 × 44 mm) |
• VIGI Network Video Recorder • Mouse • Installation Guide • Power Cord • HDD Power Cables • HDD Data Cables • Terminal Blocks • Mounting Brackets • Screws • Rubber Feet |
TP-Link VIGI NVR4064H 64-Channel NVR – Unmatched
Surveillance Power for Large-Scale Security Systems
Take your surveillance to the coming position with the TP-Link VIGI NVR4064H, a important 64-channel network videotape archivist(NVR) finagled for high-performance security monitoring. Whether you’re guarding a large marketable space, an artificial installation, or amulti-building complex, this advanced NVR delivers dependable and scalable videotape operation with enhanced clarity, storehouse, and intelligent control.
Massive Channel Support – Examiner More with lower Hassle
The VIGI NVR4064H supports up to 64 IP cameras contemporaneously, allowing druggies to connect a wide network of surveillance cameras under one centralized mecca. This is ideal for large surroundings similar as commercial premises , storages, manufactories, shopping promenades, seminaries, or government institutions where comprehensive content is critical. Each channel supports high-resolution videotape input to insure no detail goes unnoticed.
Ultra-High Definition Video Recording
Experience superior
image quality with support for over to 12MP videotape recording resolution.
Whether it’s day or night, the VIGI NVR4064H captures footage in stunning
detail, which is essential for feting faces, license plates, and other crucial
identifiers. With similar high resolution, security brigades can zoom in on
critical moments without losing clarity.
Robust storehouse Capabilities
Storehouse is noway a
concern with the VIGI NVR4064H. It comes equipped with four SATA hard drive kudos,
each supporting up to 10 TB of storehouse, for a total storehouse capacity of
over to 40 TB. This massive storehouse support is ideal for long-term recording
in high-description, icing critical footage is retained without concession.
Also, advanced videotape contraction technology like H.265 helps reduce bandwidth and storehouse consumption without immolating image quality. This ensures you save on both network coffers and hard fragment space.
Smart Video Management & Intelligent Playback
TP-Link's VIGI
software ecosystem brings smart functionality to your fingertips. The NVR4064H
integrates seamlessly with VIGI Surveillance Cameras, offering intelligent
playback, stir discovery, line crossing, intrusion discovery, and more. These
smart features allow druggies to pinpoint events and admit real-time cautions,
reducing response time in critical situations.
Playback is streamlined and effective, with multiple viewing options and timeline navigation that makes it easy to search, review, and import footage grounded on events or schedules.
Secure Remote Access Anytime, Anywhere
With the VIGI
Security App, VIGI CMS, and web interface, druggies can cover their system ever
from smartphones, PCs, or web cybersurfers. Enjoy live view, playback, and
system control from nearly anywhere with an internet connection. Advanced
encryption and secure log-in protocols insure your videotape feeds are always defended
against unauthorized access.
Easy Integration and Centralized Management
The VIGI NVR4064H
features draw-and-play connectivity with TP-Link VIGI IP cameras and supports
ONVIF compliance, enabling comity with third-party cameras for lesser
inflexibility. The intuitive interface and configuration wizard make system
setup and expansion presto and simple — indeed for druggies with limited
specialized experience.
With centralized camera operation and automatic discovery of VIGI cameras, directors can manage settings, firmware, and storehouse allocations from a single platform.
Flexible Affair Options & Multiple Display Modes
The NVR4064H supports
4K HDMI and VGA videotape affair, icing comity with a variety of observers and
display configurations. Multi-screen display options allow druggies to view
multiple channels at formerly, perfecting surveillance effectiveness and
situational mindfulness in control apartments.
Erected for trustability and nonstop Operation
Designed with
artificial-grade tackle, the TP-Link VIGI NVR4064H ensures 24/7 stability, low
failure rates, and effective heat dispersion for nonstop operation. With spare storehouse,
listed backups, and system health monitoring, it’s a result you can count on
indeed in demanding surroundings.
Crucial Features at a regard
✔ Supports up to 64 IP
channels
✔ Up to 12MP recording resolution
✔ 4 SATA kudos, up to 40 TB total storehouse
✔ Videotape contraction
✔ VIGI App & CMS support
✔ ONVIF biddable for third-party cameras
✔ Smart discovery features stir, intrusion, line-crossing, etc.
✔ Remote access, live view, and intelligent playback
✔ HDMI/VGA affair,multi-screen display
✔ Erected for 24/7 surveillance trustability
With the TP-Link VIGI NVR4064H 64-Channel NVR, businesses and institutions can make a robust and unborn-ready surveillance structure. Combining scalability, intelligence, and important storehouse, this NVR stands as a foundation of enterprise-position security results.
